Technical Parameters

Voltage: AC100~240V, 50-60HZ

Power Consumption: 351W

Light source: 295W high brightness Lamp

Lifespan: about 1500 hours

Color temperature: 8500K

Signal Control: DMX512, auto, sound

DMX Channel: 16CH

Scanning Angle: X: 540°, Y: 270°. 16bit/8bit control, dual-sensor positioning, with automatic error-correction function.

Color Wheel: 14 fixed color + white, capable of achieving multiple effects such as rainbow, semi-color, full-color, and flowing water.

Gobo Wheel: 13 fixed gobo + white, capable of achieving multiple effects such as pattern jitter and flowing water.

Prism 1: 16-faced prism, prism angle 12°.

Prism 2: 8 + 16-faced prism, prisms can rotate bidirectionally.

Main Lens: High-precision and high temperature resistant glass lens.

Other Lens: 1 frost len + 1 seven-color len.

Beam angle: 3° (without prism).

Focusing: 0 - 100% linear.

Dimming: 0 - 100% linear.

Strobe: 1 ~ 15Hz mechanical strobe.

Display: 1.7 - inch color LCD screen, capable of Chinese and English display, 180-degree inverted screen display, internal sensor information display, capable of manual control of light-spot correction, reset and other functions, display of lamps.

Appearance: High temperature resistant ABS plastic + molded alloy material.

IP Rated: IP20
