Technical Parameters

● Buttons with backlight, easy for operation;

● 12 isolated DMX output, totally 6144 channels, 1 Art-Net port;

● 2 * 15.4-inch touch screens, Intel Core I5 CPU, 120GB SSD, 4GB RAM;

● High output power supply, double silent cooling fans, make the system more stable;

● 20 playback fader, support over 1000 playback;

● Well classified Shape generator;

● Built-in music player, use time code to control the light program to make light show;

● Powerful attribute control system, CMYRGB color pickup system;

● Support handwriting remark function, easy and convenient;

● Light personality builder is built in the controller with thousands of personalities;

● High output backup power supply, to avoid data lost while the power is shut down;

● Power input：110V~220V 50~60Hz；

● Device Dimension: 96.5*55*28cm, N.W: 24 KG

● Package: 102*60*36 cm, G.W: 44 KG
