Technical Parameters

Simple framing system(4 cutting sheets,8 directions)

Voltage: AC100v-240v 50/60Hz

LED source: 400w LED module high brightness

Power consumption: 680w(FRAMING VERSION)

LED lifespan: 20000H

Beam Angle: 6~38°(FRAMING VERSION)

Signal control: DMX512,RDM

Channel: 26CH

Pan movement: 540°(16bit),auto repositioning

Tilt movement: 270°(16bit),auto repositioning

Color wheel: 7+white(FRAMING VERSION)

Rotating gobo wheel: 7+ white,bidirectional flow and shake effect

With simple framing system(4 cutting sheets, 8 directions)

Prism: 3 prism,independent bidirectional rotation

Dimming: 0~100% lineardimming

Zoom: 3 sets of optical lens,quick linear

Strobe: 0~25 hz/s

Frost: indepedent frost len,0~100% linear

Display: 2.8 inch LcD touch display,180o reverse possible

Work temperature: -10℃~40℃, good ventilation

IP rated: IP20

Product Size: 400x290x700mm; Package size: 670x550x470mm

N.W.: 25.6kg; G.W.: 28.6kg
